Honeywell Threaded Static Balancing Valve
VHS16R Series
Designed for high-performance throttling and shut-off in high-pressure steam and water systems. Its precision-machined plug and seat provide superior control over flow rates, making it ideal for process engineering. The heavy-duty construction ensures durability against thermal expansion and high-velocity fluids. These valves are commonly found in steam boiler plants and industrial manufacturing facilities.
Feature | Specification |
Pressure Rating | PN16 |
Size Range | DN15 to DN50 |
Applicable Medium | Cold water, hot water, or Glycol solution (up to $50\%$ concentration) |
Water Quality Standard | GB/T29044-2012 |
Medium Temperature | $-20^{\circ}\text{C}$ to $+130^{\circ}\text{C}$ |
Body / Stem / Trim Material | Forged Brass |
Sealing Material | FKM (Viton) |
Hand Wheel Material | PA66 + Fiberglass (reinforced polymer) |
Connection Type | Threaded (ISO 7-1) |
Leakage Rate | Zero Leakage (Bubble-tight shutoff) |
